5
Adjust the mouting base's position
and tighten the screws.
Put the wires in th groove and
insert the buckle.
Slide the panel into the mounting
base.
Installation completed. Remove the
sticker.
Model B
If you already have a peephole, install the device in the same place. If not, please drill a hole of diameter about 16.5mm (no
more than 45mm) and about 145cm distance from the ground to have a good viewing effect.
Measure the door's thickness and select the appropriate screws.
Thickness Screw
35 to 60mm
60 to 85mm
85 to 105mm
Turn the screws into the back of
camera.
Tear off the release paper.
Pass screws and wire through the
door. You can roll up the paper to help.
Adjust camera's position and push
it close to the door gently.
Take out the base, and plug the
connector into the slot on the
bottom of the base.
Pass screws through the mounting
holes.
To Next Page
