26 www.faberre.com
Alimentation
Diagramme de câblage du ventilateur
3/23858/0 ‑ C7 AU CÂBLE NEMA1‑15 P
C8 MÂLE
CONNECTEUR
AU MODULE
MOTEUR DU VENTILATEUR
EXTRACTEUR
