6
4. CONTROLS
BUTTON FUNCTIONS
L Light Turns the Lighting System on and off.
V1 Speed Turns the Motor on at Speed one.
Turns the Motor off.
V2 Speed Turns the Motor on at Speed two.
V3 Speed Turns the Motor on at Speed three.
5. LIGHTING
Lamp Power (W) Socket Voltage (V) Dimension (mm) ILCOS Code
4 E14 220 – 240 107 x 37 DRBB/F-4-220-240-E14-35/100
