16
CHOOSE YOUR DUCTING METHOD
Ducted Venting Installation
8
Non Ducted -
Recirculation Option
Install Damper that is included with the
Hood before connecting to the ductwork.
Install Roof or Wall Cap purchased
separately. Connect the ø 5" metal duc-
twork to the Roof or Wall Cap and then
attach ductwork.
´
For Non-Ducted Recirculation venting,
route the ductwork to a location above the
hood where the discharge is vented back
into the room.
Use the included Recirculation Vent Grill to
cover the opening. Secure the grill with the
2 screws provided in the Install Kit.
Required Activated
Charcoal Filter Accessory
- sku # - FILTER4
4 15/16"
12e
8
Torx Screwdriver
To Next Page
