Faber INCA SMART - Light Bulb Replacement Procedure; Steps for Replacing Hood Lamps

22
Light Bulb Replacement
• Remove grease lters and set aside.
• Remove the bottom of the Range Hood by 4 screws 12b as shown.
• Replace the lamp with a new one of the same type.
• Replace the bottom of the Range Hood by 4 screws 12b.
• Replace the grease lters.
E12 self-ballasted led lamps –
listed in accordance with ul 1993/
nmxj-578/1-ance/ csa c22.2 No.
1993
12b
