Faber MATRIX EG10 X A90 ACTIVE User Manual

EN
6
6
CHARACTERISTICS
Dimensions
Min.
250mm
Min.
250mm
1270
MIN. 1270 - MAX. 1720
Components
Ref. Q.ty Product Components
1 1 Hood Body, complete with: Controls, Light, Blower,
Filters
2.1 1 Upper Section
2.2 1 Lower Section
8 1 Directional Air Outlet grille
9 1 Flange
16 1 Filter cover
Ref. Q.ty Installation Components
7.2.1 2 Upper Chimney Section Fixing Brackets
11 6 Wall Plugs
11a 2 Wall Plugs SB 12/10
12a 6 Screws 4,2 x 44,4
12c 10 Screws 2,9 x 6,5
12d 2 Screws 2,9 x 9,5
Q.ty Documentation
1 Instruction Manual
1
16
12c
11
12a
12d
8
2.1
2.2
12c
9
12a
7.2.1 11
11a

Faber MATRIX EG10 X A90 ACTIVE Specifications

General

Brand	Faber
Model	MATRIX EG10 X A90 ACTIVE
Category	Ventilation Hood
Language	English
