Appendix A: Server Hardware Specifications
 Warning: Be sure to remove all power before servicing the unit. See label
affixed on the unit for power ratings.
Dimensions and Weight
Product
Weight
Board
Depth
Width
Height
Facilis
Hub
Server
10.9kgs / 24lbs
ATX(12"x 9.6")
17.7 in
44.96
cm
19 in
48.26
cm
3.5 in
(2u)
8.89 cm
Power Supplies
Redundant 350W Power supplies are hot-swappable while the server is in operation. Please read the
following procedure for swapping a power supply unit.
1. Locate the failed power supply by the flashing amber light on the unit.
2. Remove the AC power cord from that power supply unit.
3. Press the green tab to the right to free the power supply from the chassis.
4. Pull on the handle to remove the power supply.
5. Slide the new power supply into the slot, and lock into place.
6. Attach AC power cord to the replacement power supply in the chassis.
Cooling Units
3x (80 mm = 42.5CFM ea.) Fans
Drive bays
2 x 2.5” SSD Redundant
Environment
Max Ambient Temp: 30C / 86F
Min Ambient Temp: 5C / 41F
Humidity - 5% - 95% Non-condensing
Electrical Input
100-240 Vac, 3-1.5 A per power cord
50-60Hz
Auto switching
Multiple power sources. Disconnect all power cords before servicing. See user guide for additional
Warnings.
Hub Server (dual PSU)
Startup: ~250W
Idle: ~120W
Active: ~160W
Ports
6x USB Ports (2x front; 4x rear)
