Connectivity
Fibre Channel Cable - Multimode 50 or 62.5/125 Full Duplex
Fibre Channel Terminations - LC (square small form factor)
Fibre Channel Tolerance - .5 DB/jump, Max 6DB/run P2P
Ethernet Cable - Cat6a or higher rated for 10Gbit
Multimode 50/125
Ethernet Connector - RJ45 for Gbit
LC for 10 Gb
Fibre Channel Cable Specifications and Length
Micron Max Distance by optical cable 4/8/16/32Gbs
9 µm (OS1) Single mode 10km/10km/NA/NA
50 µm (OM4) Multi mode 4700 MHz 400m/190m/125m/100m
50 µm (OM3) Multi mode 2000 MHz 380m/150m/100m/70m
50 µm (OM2) Multi mode 500 MHz 150m/50m/35m/20m
62.5 µm (OM1) Multi mode 200 MHz 70m/21m/15m/NA
Ethernet Cable Specifications and Length
UTP Length Max 1Gbit
CAT 5E, CAT 6 or CAT 7 100m
UTP Length Max 10Gbit
CAT 6 or CAT 7 100m
Optical Fiber Length Max 10Gbit
50 µm (OM3) 300m
