ELECTRICAL POWER CONNECTIONS
Accessory Electrical connections
Dip-switch setting and LED indication of functions
12
Signal led lights:
Output for intermittent signal led
lights during the movement both
rising and lowering and also on
dwell in up position: the lights are
o only when the bollard is in down
position.
Connect the blue-common wire
and the brown wire of the bollard
ashing light cable.
Signal led lights output
230 V - 100 W max
BLUE
COMMON
BROWN
5251 53
Acoustic signal “beeper”
during movement:
PCB power supply:
The acoustic signal device inside
the bollard is active duringrising
and lowering. The connection wires
are the blue-common and the
black one of the ashing light
cable.
Acoustic signal device
230 V - 100 W max
PCB power supply
230 V ±10% 50 Hz single phase
BLUE
COMMON
BLACK
LIVE
F N
NEUTRAL
5251 53
Electronic programmer power
supply.
2322 24 25
External ashing lamp:
It is possible to connect both the
external ashing lamp and the
intermittent signal led lights which
are on only during the rising and
lowering movement. The cable for
the connection is the one labelled
as ashing lights cable.
l'apricancello
230 V - 100 W max
COMMON
5251 53
ON: pre-ashing
OFF: no pre-ashing
DIP-SWITCH N° 4 and N° 10:
4
ON: ashing light out of service on dwell time.
Automatic mode
OFF: light ashes on dwell time. Automatic mode
10
