Faema E61 2 GR - Component and Function Legend; Component and Function Legends by Language

97
Legenda - Legend - Legende - Legende - Leyenda - Legenda
LEGENDA
1 = Interruttore generale 2 = Switch motore pompa 20 = Sonda livello 21 = Motore pompa 22 = Condensatore pompa 23 = Pressostato 24 = Resistenze caldaia 25 = Protettore termico caldaia 26 = Scheda autolivello 34 = Elettrovalvola livello 49 = Scheda led 50 = Interruttore led 59 = Fusibili pompa * I componenti - * - sono applicati solo in DOFXQHFRQ¿JXUD]LRQLGLSURGRWWL
LEGEND
1 = Main switch 2 = Pump motor switch 20 = Level probe 21 = Pump motor 22 = Pump capacitor 23 = Pressure switch 24 = Boiler heating element 25 = Boiler thermal cut-out 26 = Automatic level board 34 = Automatic level solenoid valve 49 = Led electronic board 50 = Led switch 59 = Pump fuses * ,WHPVPDUNHGDUH¿WWHGLQVRPH SURGXFWFRQ¿JXUDWLRQVRQO\
LEGENDE
1 = Interrupteur général 2 = Switch moteur pompe 20 = Sonde niveau 21 = Moteur pompe 22 = Condensateur pompe 23 = Pressostat  5pVLVWDQFHFKDXGLqUH  3URWHFWHXUWKHUPLTXHFKDXGLqUH 26 = Fiche niveau automatique 34 = Electrovalve niveau 49 = Carte led 50 = Interrupteur led 59 = Fusibles pompe * Les détails - * - ne sont appliqués TXjFHUWDLQHVFRQ¿JXUDWLRQV de produit.
I GB F
LEYENDA
1 = Interruptor general 2 = Switch motor bomba 20 = Sonda nivel 21 = Motor bomba 22 = Condensador bomba 23 = Presostato 24 = Resistencia caldera 25 = Protector térmico caldera  7DUMHWDHOHFWUyQLFD 34 = Electroválvula nivel  7DUMHWDOHG 50 = Interruptor led 59 = Fusible bomba * /RVGHWDOORVVHSXHGHQDSOLFDUVyOR HQDOJXQDVFRQ¿JXUDFLRQHVGHOSURGXFWR
LEGENDE
1 = Hauptschalter 2 = Schalter Pumpenmotor  6WDQGIKOHU 21 = Pumpenmotor 22 = Pumpenkondensator  'UXFNZlFKWHU 24 = Heizelemente Heizkessel 25 = Schutzschalter Heizkessel 26 = Karte elektronische Standkontrolle 34 = Magnetventil Wasserstand 49 = Led-Karte 50 = Led-Schalter 59 = Sicherungen pumpe * Die mit - * - gekennzeichneten Kompo- nenten sind nur in bestimmten Modellen installiert.
LEGENDA
1 = Interruptor geral 2 = Switch motor bomba 20 = Sonda de nível 21 = Motor bomba 22 = Condensador das bombas  3UHVVyVWDWR 24 = Resistência da caldeira 25 = Protector térmico da caldeira 26 = Ficha autonível 34 = Electroválvula nível 49 = Ficha led 50 = Interruptor led 59 = Fusível da bomba * 2VSRUPHQRUHVVmRDSOLFDGRV DSHQDVHPDOJXPDVFRQ¿JXUDo}HVGH produto.
D E P
