83
4
Use only the new hoses supplied with the machine. Do not re-use hoses.
A supply hose with seals is inside the drum of the machine.
Water pressure min 0.03 MPa (0.3 bar), max 1 MPa (10 bar).
The drain hose is at the back of the machine. Fix the drain hose so that it does not
move while the washing machine is in operation. If necessary, use the elbow (1).
3
Connect the water supply
Water drain
1). after connecting, make sure the hose is not twisted
2) after connecting the hose and the valve, check they are sealed tight
3). regularly check the condition of the hose.
Supply the machine with cold water only.
Connection on the left Connection on the right
(1)
