6 8025/8030 CNC OPERATING MANUAL
8. CL. To delete characters one by one during the editing process, etc.
9. INS. Key which allows characters to be inserted during the edition of a program block.
10. Arrow keys for moving the cursor.
11. Page up and page down keys.
12. SP. Reserves a space between characters of a comment.
CAPS. Allows characters to be edited in capitals.
SHIFT. Allows characters to be edited which are found on keys with double meaning.
13. JOG keys for manual displacement of the axes.
14. RAPID FEED button.
15. Switch (M.F.O.), which allows a % variation of the programmed feed and to choose the
different ways of working in the JOG MODE (continuous, incremental, electronic
handwheel).
16. Spindle operating keys. Allow the spindle to be put into OPERATION and to STOP it,
in the JOG operating mode. The and keys allow a % variation of the programmed
turning speed of the spindle during operation.
17. START. Cycle START key.
18. STOP. Cycle STOP key.
