8 8025/8030 CNC OPERATING MANUAL
3. OPERATING MODES
The CNC has 10 different operating modes:
0. AUTOMATIC : Execution of programs in a continuous cycle.
1. SINGLE BLOCK : Execution of part programs block by block.
2. PLAY-BACK : Creation of a program in memory while the machine is being operated
manually.
3. TEACH-IN :
-Creation and execution of a block without entering it into memory.
-Creation, execution and entering of a block into memory; thus a program is created
while being executed block by block.
4. DRY RUN : To check programs before actual execution of the first part.
5. JOG/HOME SEARCH :
- Manual movement of the machine.
- Machine-reference. (Home search).
- Presetting of any value and zero-setting the axes.
- Entering and executing of F,S,M.
- Setting initial conditions of the tool magazine.
- Handwheel operation.
