10 8025/8030 CNC OPERATING MANUAL
3.1. 0 MODE: AUTOMATIC (Continuous cycle)
1 MODE: SINGLE BLOCK
The only difference between these two modes is that in single block mode (1), each time a block
is executed the CYCLE START button has to be pressed to continue exe-
cuting the program, whereas in automatic mode (0) the cycle is continuous.
3.1.1. Execution of a program
The execution of a program requires the following steps:
3.1.1.1. Selection of the AUTOMATIC operating mode (0).
SINGLE BLOCK (1)
- Press OP MODE : The list of 10 operating modes appears on the screen.
- Press 0/1 key : The standard display corresponding to this operating mode appears; i.e. in
the upper left-hand section of the screen the message AUTOMAT/SINGLE BLOCK
followed by the number of the program P —— and the number of the first block to be
executed N ——.
3.1.1.2. Selection of the program to be executed
Whenever a program number is wanted other than that appearing on the screen, the following
sequence should be followed:
- Press the P key
- Key in the number of the desired program
- Press RECALL
The new program selected will appear on the screen, if it exists. If not, the screen will display:
N*
