12 8025/8030 CNC OPERATING MANUAL
3.1.1.5. Cycle Start
- Press
. Once the program and block number have been selected, just press this key to execute the
program in AUTOMATIC or the block in SINGLE BLOCK.
. If the program contains any conditional block it will be executed when the relevant input
is activated (see INSTALLATION AND START-UP MANUAL). If it is not activated, the
CNC will disregard such block.
. During the time that the fast travel button is pressed carrying out a movement
in G01, G02, or G03, the percentage of the feedrate will be 200% of the programmed
feedrate, whenever the machine parameter P606(2) has a value equal to zero. This will
happen when the external input START is activated, if parameter P609(7) = 1.
. In the SINGLE BLOCK mode all those blocks which are programmed with parameters
will be executed by the FAGOR CNC as if they were a single BLOCK, whenever these are
in canned cycles.
3.1.1.6. Cycle stop
- Press
The CNC stops the execution of the block in progress. To resume the cycle just press .
The cycle is also stopped by means of:
- Codes M00,M02,M30,M06 [M06 depending on parameter P601(8)].
- Code M01 when the relevant input is activated.
- The external signal FEED HOLD (the cycle continues when the signal disappears)
- The external signal EMERGENCY STOP (in this case the program must be restarted,
since the CNC is reset to initial state).
- The external STOP signal
If machine parameter P727 has a value between 1 and 99, when the external STOP input is
activated while running a program, the CNC will interrupt the program and jump to execute
the standard subroutine corresponding to the number assigned to P727.
