8025/8030 CNC OPERATING MANUAL 19
3.1.5. Verification and modification of the values of the tool offset table without stopping
the cycle.
- Press the function key [TOOL OFFSETS]
- Key in the number of the offset desired (00-99).
- Press RECALL.
The values of the offset which has been called will appear on the screen.
Underneath and to the right, the letter I will appear.
If it is wished to modify the value of the I on the table, the amount which it is wished to add
or subtract is keyed in.
The value keyed in appears on the right of the I.
- Press K
- Key in the value to be added or subtracted
- Press ENTER
Once the values of the tool offset table have been introduced, press the key [END] to return
to the standard display.
3.1.6. Tool inspection.
If during the running of a program it is wished to inspect or change a tool, the procedure to
follow is indicated below:
a) Press
The programme being run will be interrupted and on the upper right-hand side of the screen
the message INTERRUPTED shall appear.
b) Press the function key [TOOL INSPEC].
At this time, M05 is run.
On the screen, there will appear:
JOG KEYS AVAILABLE
EXIT
