20 8025/8030 CNC OPERATING MANUAL
c) By means of the JOG keys, the axes can be moved to the desired point.
The TOOL INSPECTION sequence allows the spindle to start and stop during the
removal of the tool, by means of the spindle operating keys situated on the Control
panel.
d) Once the tool has been inspected or changed:
Press [CONTINUE] (According to the situation when [TOOL INSPEC] is pressed, M03
or M04 are executed).
The screen will show:
RETURN
AXES NOT POSITIONED
(Axes which have been moved manually).
By means of the JOG keys the axes are taken to the position in which the cycle was
interrupted. The CNC will not allow this position to be passed.
When the axes are in position, on the screen there will appear:
RETURN
AXES NOT POSITIONED
NONE
e) Press
The cycle will continue normally.
