8025/8030 CNC OPERATING MANUAL 21
3.1.7. CNC reset
In AUTOMATIC and SINGLE BLOCK operating modes, when the RESET key is pressed
twice, the CNC is reset to switch-on conditions.
When the RESET key is pressed the first time, the blinking message RESET? will appear on
the screen. If RESET is not desired, press CL to cancel it.
3.1.8. Display and deletion of messages sent by the FAGOR PLC 64
The CNC operates with the FAGOR PLC and the latter sends messages for display on the
CNC, it is possible to access to a table of messages which are active at that moment.
The CNC always displays the message with most priority, if there is more than one active
message, the + sign will be highlighted (displayed in reverse video).
To display the table, it is necessary to press the [PLC MESSAGES] function key.
If there is such a number of messages that they occupy more than one screen, by pressing
keys and it is possible to display these.
One of the messages will appear highlighted indicating that it can be deleted from the table by
pressing the DELETE key.
When a deletion is made in this way, the CNC will deactivate the MARK corresponding to the
PLC which sent the message.
To select the message to delete the and keys must be used.
