8025/8030 CNC OPERATING MANUAL 23
3.2.7. Creating a program
The creation of a program in PLAY BACK mode is the same as in EDITING mode except
that the axes can be moved by means of the JOG keys. The axis coordinate values are displayed
at the bottom of the screen.
In a block which only contains the coordinates of one point, after using the JOG keys to move
the axes, press ENTER and the coordinates of the point will be stored in the memory. Every
time the ENTER key is pressed, the coordinates of the point according to the 3 active axes at
that moment will be stored in memory.
In order to activate an axis which is not active at that time, the key of the corresponding axis
(X,Y,Z,W,V) must be pressed.
If in addition to the coordinates of a point it is desired to write into the block further information
such as G,S,M,T functions etc., each time the key of the corresponding axis is pressed the CNC
will take as the value of the axis the coordinate at which the machine is at that moment.This
method of editing is highly practical when creating a program for copying a part using functions
G08 and G09.
When G08 has been written into a block requiring it, use the JOG keys to move the machine
to the end point of the tangent arc to the previous path, then press ENTER and the block will
be stored in the memory.
When G09 has been written into a block which requires it, use the JOG keys to move the
machine to an intermediate point on the arc and press the ENTER key. The CNC will take the
coordinates as those of the intermediate point on the arc. Then move the machine to the end
point of the arc and once the ENTER key has been pressed the block will be stored in the
memory.
Atention:
If the value 1 is entered in the machine-parameter P610(3), the START input
is equivalent to ENTER key in PLAY-BACK operating mode.
3.2.8. Deletion of a block
Same as in EDITING mode (6).
3.2.9.Copy a program
Same as in EDITING mode (6).
