Electrical connection
Warning!
All electrical work should be carried out by a
No alterations or wilful changes in the electric-
ity supply should be carried out.
The oven is manufactured to work with a one-
-phase alternating current (230V 1N~50Hz)
and is equipped with a 3 x 1,5 mm
2
connec-
tion lead.
The electricity supply for the oven must have
a safety switch which enables the power to
between the working contacts of the safety
switch must be at least 3 mm.
Before connecting the oven to the power sup-
ply it is important to read the information on
the data plate and the connection diagram.
Caution! The installer is obliged to provide
the user with “appliance electrical connection
Live L: BN - brown
Neutral N: BU - blue
a 16A fuse.
Recommended type of connection lead:
H05VV-F, 3 x 1,5mm
2
.
Connection diagram
Caution! Voltage of heating elements 230V.
Caution! In the event of any connection the safety
wire must be connected to the
GNYE
N
BU
BN
L
Important!
should be replaced at the manufacturer or at
person to avoid danger.
INSTALLATION
49
