Fagor AE-061 - Control Holder; Portamandos Parts List

1 12046659 CONTROL TARJETA CAM.12V AC .
2 12046671
VISUALIZADOR 12V AC 50/60Hz 12D
3 12043668
SOPORTE PROGRA. CONCEPT ADV.
4 12043680 PORTAMANDOS ACE 061
4 12039625 PORTAMANDOS APE 061
4 12043806 PORTAMANDOS ACE101
4 12043767 PORTAMANDOS APE-APG 101
S/Nº 12093219 FRENTE PORTAM. CONCEPT
S/Nº 12041815 JUNTA PORTAMANDOS ADV PLUS
5 12044109
SERIGRAFIA CONCEPT ADVANCE E.
6 12046201 BOTON CONCEPT ADV
16.09.13CONTROL PANEL APE-APG 101 _ 1
16.09.13
CONTROL PANEL SEAL ADV PLUS
1 1
16.09.13CONTROL PANEL FRONT CONC. 1 1
16.09.13CONTROL PANEL APE 061 1 _
CONTROL BUTTON CONC. ADV 2 2
SERIGRAPHY CONCEPT ADVAN 1 1
16.09.13CONTROL PANEL ACE101 _ 1
16.09.13CONTROL PANEL ACE 061 1 _
CIRCUIT SUPPORT CONCEPT AD
1 1
12V AC 50/60Hz 12D DISPLAY 1 1
INTRODUCID.
INTRODUCED
NOTAS
CARD CONTROL 12V AC 50/60Hz 1 1
ELIMINADO
ELIMINATED
C-3008
ITEM
CODIGO
REFERENCE
DENOMINACION DENOMINATION
ACE-061 ACE-101
MOD.
HORNOS / OVEN ZONA / ZONE
CONJUNTO ELECTRICO PORTAMANDOS / CONTROL
HOLDER ELECTRIC UNIT
PLANO
DIAGRAM
- 23-
