Fagor AE-061 User Manual

1 12039460 REFUERZO MOTOR
12009944 ARANDELA A5
12009890 ARANDELA ABANICO A5 A.304
12010221 TORNILLO EXAGONAL M5X15
2 12039615 SOPORTE MOTOR
S/Nº 12039614 PERFIL SOPORTE MOTOR 061
S/Nº 12039493 PERFIL SOPORTE MOTOR 101
12010163 REMACHE EXAGONAL M.5
12010238 TORNILLO EXAGONAL M5x10
3 12046360 CUERPO INT. COMPL. ACE 061
3 12043399 CUERPO INT. COMPL. ACE 061
3 12046356 CUERPO INT. COMPL. AE 061
3 12043423 CUERPO INT. COMPL. AE 061
3 12046349 CUERPO INT. COMPL. APE 061
3 12043411 CUERPO INT. COMPL. APE 061
3 12046387 CUERPO INT. COMPL. ACE 101
3 12043780 CUERPO INT. COMPL. ACE 101
3 12046385 CUERPO INT. COMPL. AE 101
3 12043507 CUERPO INT. COMPL. AE 101
3 12046379 CUERPO INT. COMPL. APE 101
3 12043742 CUERPO INT. COMPL. APE 101
12010002 REMACHE EXAGONAL M.4 INOX
12010267 ARANDELA 16X6X1.2 A.304
12009882 ARANDELA ABANICO A6 A.304
12010186 TORNILLO EXAGONAL M6X15 A30
4
S/Nº 12023935 PUNTA DIFUSORA LAVADO
4 12039529 SOPORTE LIMITADOR CAMARA
12009868 ARANDELA PLANA INOX 6MM
12009882 ARANDELA ABANICO A6 A.304
12010255 TORNILLO EXAGONAL M6 INOX.
_ 01.10.12INTERIOR FULL BODY ACE 101 ___1_
_ 01.10.12INTERIOR FULL BODY APE 061 __1__
2HEXAGONAL SCREW M6 INOX. 22222
2FAN SHAPED WASHER A.6 22222
2WASHER FLAT 6 MM INOX. 22222
1LIMITER BRACKET CAMERA 11111
1WASHING DISPENSER POINT __1__
4HEXAGONAL SCREW M6X15 44444
4FAN SHAPED WASHER A.6 44444
4FLAT WASHER 16X6X1.2 A.304 44444
4HEXAGONAL RIVET M.4 INOX 44444
1 01.10.12INTERIOR FULL BODY APE 101 _____
_ 01.10.12INTERIOR FULL BODY AE 101 ____1
_ 01.10.12INTERIOR FULL BODY ACE 101 ___1_
_ 01.10.12INTERIOR FULL BODY APE 061 __1__
_ 01.10.12INTERIOR FULL BODY AE 061 _1___
_ 01.10.12INTERIOR FULL BODY ACE 061 1____
4HEXAGONAL BOLT M5x10 44444
8HEXAGONAL RIVET M.5 88888
2RAIL MOTOR 101 ___22
_RAIL MOTOR 061 222__
1SOPORTE MOTOR 11111
4HEXAGONAL BOLT M5X15 44444
4FAN SHAPED WASHER A.5 44444
4FLAT WASHER A.5 44444
INTRODUCID.
INTRODUCED
NOTAS
MOTOR REINFORCEMENT 111111
ACE-101
AE-101
APE-101
ELIMINADO
ELIMINATED
C-3002
ITEM
CODIGO
REFERENCE
DENOMINACION DENOMINATION
ACE-061
AE-061
APE-061
MOD.
HORNOS / OVEN ZONA / ZONE MUEBLE INTERIOR / INTERIOR OVEN
PLANO
DIAGRAM
INTERIOR FULL BODY ACE 061 1_____ 01.10.12
INTERIOR FULL BODY AE 061 _1____ 01.10.12
INTERIOR FULL BODY AE 101 ____1_ 01.10.12
INTERIOR FULL BODY APE 101 _____1 01.10.12
- 7-
FAGOR INDUSTRIAL
