12046015
KIT PUERTA 061
12046018
KIT PUERTA 101
1
12046041
KIT CRISTAL INTER. 061
1
12046042
KIT CRISTAL INTER. 101
2 12041724 BISAGRA CRISTAL INTERIOR
12010209 TORNILLO AVELLANADO M5X15
3 12039312 BISAGRA SUPERIOR
12009882 ARANDELA ABANICO A6 A.304
12010106
TORNILLO ALLEN INOX. M6X35MM
4 12023636 EJE SUPERIOR
12023631 ARANDELA AMARRE
12023716 RESORTE 06329
12009882 ARANDELA ABANICO A6 A.304
12010186
TORNILLO EXAGONAL M6X15 A304
6 12043391 BISAGRA INFERIOR ADVANCE
7 12039311
BASE BISAGRA INFERIOR PUERTA
7 12047967 BASE BISAGRA INFERIOR 6 DIEN
12009890 ARANDELA ABANICO A5 A.304
12009944 ARANDELA A5
12010238 TORNILLO EXAGONAL M5x10
12010199 TORNILLO AVELLANADO M6x16
8 12047580 REP. MANILLA 1/1 ADVANCE
12010262 TORNILLO AVELLANADO M4X15
9 12024560 INTERRUPTOR MAGNETICO AC
10 12022166 SOPORTE MICRO PUERTA
12010242 TORNIL. APLASTADO M5X13 A 304
11
12041725
MUELLE CIERRE CRISTAL INTERIOR
12 12039485 RECOGEAGUAS PUERTA 101
12009944 ARANDELA A5
12009890 ARANDELA ABANICO A5 A.304
12010242 TORNIL. APLASTADO M5X13 A 304 3FLAT SCREW M.5x13 3 3 3 3 3
1 02.09.13LOWER DOOR HINGE BASE 1 1 1 1 1
MOD.
HORNOS / OVEN ZONA / ZONE PUERTA / DOOR
PLANO
DIAGRAM
C-3001
ITEM
CODIGO
REFERENCE
DENOMINACION DENOMINATION
ACE-061
AE-061
APE-061
ACE-101
AE-101
APE-101
ELIMINADO
ELIMINATED
INTRODUCID.
INTRODUCED
NOTAS
DOOR 061 KIT 1 1 1 _ _ _
DOOR 101 KIT _ _ _ 1 1 1
061 INNER GLASS KIT 1 1 1 _ _ _
101 INNER GLASS KIT _ _ _ 1 1 1
INNER GLASS HINGE 2 2 2 2 2 2
COUNTERSUNK SCREW M.5x15 2 2 2 2 2 2
UPPER HINGE 1 1 1 1 1 1
FAN SHAPED WASHER A.6 3 3 3 3 3 3
ALLEN BOLT STAINLE.M6X35MM
3 3 3 3 3 3
UPPER SHAFT 1 1 1 1 1 1
DOOR ANCHORING WASHER 1 1 1 1 1 1
SPRING 06329 1 1 1 1 1 1
FAN SHAPED WASHER A.6 1 1 1 1 1 1
HEXAGONAL SCREW M6X15 1 1 1 1 1 1
BOTTOM HINGE ADVANCE 1 1 1 1 1 1
LOWER HINGE BASE 1 1 1 1 1 1 02.09.13
FAN SHAPED WASHER A.5 1 1 1 1 1 1
FLAT WASHER A.5 1 1 1 1 1 1
HEXAGONAL BOLT M5x10 1 1 1 1 1 1
COUNTERSUNK SCREW M6x16 4 4 4 4 4 4
HANDLE 1/1 ADVANCE 1 1 1 1 1 1
COUNTERSUNK SCREW M.4x15 3 3 3 3 3 3
MAGNETIC SWITCH AC 1 1 1 1 1 1
DOOR MICRO SWITCH 1 1 1 1 1 1
FLAT SCREW M.5x13 1 1 1 1 1 1
INNER GLASS SPRING LOCK 1 1 1 1 1 1
DOOR SPRING WATER COLLECTOR 6-10/11
1 1 1 1 1 1
FLAT WASHER A.5 3 3 3 3 3 3
FAN SHAPED WASHER A.5 3 3 3 3 3 3
- 4-
FAGOR INDUSTRIAL
