Fagor APE-101 - Page 17

15 12003183 SOPORTE MICROS LAVADO
12010163
REMACHE EXAGONAL M.5
16 12023796 PUNTA ACOPLE MOTOR A VALVUL
S/Nº 12019645 JUNTA TORICA Ø10x3.5
S/Nº 12010273 MANG. SUJEC. 4X14 DIN1481
17 12024796 CUERPO VALVULA COMPLETO
12010081 JUNTA TORICA Ø52X3,5
12010131 JUNTA TORICA Ø33x3,5
12024532 JUNTA TEFLON VALVULA
12009181 JUNTA TEFLON VALVULA
18 12024407 GOMA VALVULA BOMBA GAS
12010023 ABRAZADERA 20-32
12009997 ABRAZADERA 25-40
19 12001778 SOPORTE BOMBA LAVADO
12010090 REMACHE AVINOX Ø4X7,5MM
20 12024708 MOTOBOMBA ACLARADO
S/Nº
12093684
KIT VALVULA DESAGUE ADVAN.
S/Nº 12025198 MANGUERA ENTRADA AGUA
S/Nº 12024463 CONDENSADOR ELEC. 250V VDE
21 12047404 MOD CONJUNTO DESAGUE ADV
12.07.13
1MOTOR-PUMP _ _ 1 _ _
1
CLAMPING SLEEVE 4x14 DIN 1481
_ _ 1 _ _
1WATER INLET HOSE 1 1 1 1 1
1VALVE DRAIN ADVANCE KIT _ _ 1 _ _
4AVINOX RIVET Ø4X7,5MM _ _ 4 _ _
1WASH PUMP SUPPORT _ _ 1 _ _
1CLAMP 25-40 _ _ 1 _ _
1CLAMP 20-32 _ _ 1 _ _
1PUMP VALVE RUBBER GAZ _ _ 1 _ _
2TEFLON VALVE BOARD _ _ 2 _ _
2TEFLON VALVE BOARD _ _ 2 _ _
1O-RING Ø33x3.5 _ _ 1 _ _
1O-RING Ø52X3.5 _ _ 1 _ _
1COMPLETE VALVE BODY _ _ 1 _ _
1O-RING Ø10X3.5 _ _ 1 _ _
1CONN. POINT MOTOR TO VALVE _ _ 1 _ _
1 03,12,12ADV DRAIN SET MODEL 1 1 1 1 1
1CONDENSER ELEC. 250V VDE 1 1 1 1 1
INTRODUCID.
INTRODUCED
NOTAS
ACE-101
AE-101
APE-101
ELIMINADO
ELIMINATED
C-3005
ITEM
CODIGO
REFERENCE
DENOMINACION DENOMINATION
ACE-061
AE-061
APE-061
MOD.
HORNOS / OVEN ZONA / ZONE CONDUCCIONES DE AGUA / WATER PIPES
PLANO
DIAGRAM
MICROS WASH STAND _ _ 1 _ _ 1
HEXAGONAL RIVET M.5 _ _ 4 _ _ 4
- 16-
FAGOR INDUSTRIAL
