Fagor APE-101 - Remache Exagonal M

13 12023553 EMBELLECEDOR POSTERIOR ASA
12010262 TORNILLO AVELLANADO M4X15
14 12023849 ANCLAJE PUERTA
15 12039599 JUNTA PUERTA COMPL. 061
15 12039475 JUNTA PUERTA COMPL. 101
12009970 REMACHE EXAGONAL M.5 INOX
MOD.
HORNOS / OVEN ZONA / ZONE PUERTA / DOOR
PLANO
DIAGRAM
C-3001
ITEM
CODIGO
REFERENCE
DENOMINACION DENOMINATION
ACE-061
AE-061
APE-061
INTRODUCID.
INTRODUCED
NOTAS
ACE-101
AE-101
APE-101
ELIMINADO
ELIMINATED
REAR TRIM HANDLE 1 1 1 1 1 1
COUNTERSUNK SCREW M.4x15 2 2 2 2 2 2
DOOR JOINT 061 1 1 1 _ _ _
DOOR JOINT 101 _ _ _ 1 1 1
DOOR ANCHORING 1 1 1 1 1 1
HEXAGONAL RIVET M.5 INOX 2 2 2 2 2 2
- 5-
FAGOR INDUSTRIAL
