The ZWR radio communication module built into the ARZ Z-Wave roller shutter is placed under the right
shutter casing cover – see Figure 2.
11.09.19 NC817 3/8 ©2011, FAKRO
Figure 2: Description of place of ZRW module
12VDC motor
power
12VDC power
(free polarisation)
Place of connecting
the control panel
(see Figure 1)
