Falcon FLO - Display Overview and Icons; Button Functions and Speed Modes

Page 16
Speed mode 0 : no assistance , pure pedaling mode
Indicates the front light is on
Indicates the brake is working
Indicates the throttle is not working or not working properly
Indicates the motor is not working or not working properly
Indicates the controller is not working or not working properly
Switch among single trip mileage , total mileage and running time
The figures of single trip mileage , total mileage and running time
Speed mode 1 : low assistance , top speed 12km/h
Speed mode 2 : mid assistance , top speed 18km/h
Speed mode 3 : high assistance , top speed 25km/h
Battery percentage
Button functions: Icons’ meaning:Speed modes:
+button
M button
- button
Battery level
Speed
Speed mode
Fig.1
PEDAL ASSIST SYSTEM
M: The multifunctional button, long
press for 3 seconds to switch on/
o󰀨;shortpresstoswitchthedisplay
of single trip mileage, total mileage
and running time.
+:Longpressfor3secondstoturn
on/o󰀨thefrontlight,shortpressto
switch gear.
-: Short press to switch gear
