How to fold the bike (Only for folding bike)
1. Unlock the handlebar quick release lever
(Fig.1(A)) and push down down the handlebar
to the lowest position, then lock the handlebar
quick release lever.
2. Unlock the handlebar quick release lever
(Fig.2(A)) and rollover The handle bar.
3. Rotate the pedal upward so it is perpendicular to
the ground (Fig.3(A)).
4. Release the lock lever from its clasp on the right
side of the E-Bike (Fig.4(A)).
5. Rotate the lock lever (Fig.4(A)) clockwise until it
points backward pull the lock nut and rotate the
lock nut (Fig.4(A)) out away from the E-Bike until
the nut clears the lock plate (Fig.4(A)).
6. Grasp the seat and the handlebar. Pivot the front
half of the frame rearward around the hinge until
the front wheel is beside the rear wheel (Fig.5).
FOLDING INSTRUCTIONS
Fig.1 Fig.2
Fig.3 Fig.4
Fig.5
