fallprotec Securope 2012 - Attach to the Cable; Use of the Glider LDV001

User Manual
Securope 2012 horizontal
DOC039-UK-19.07.15
20
Fig. 21 Fall indicator not activated Fig. 22 Fall indicator activated
9.1.1. Attach to the cable
The user attaches to the cable in an area where there is no risk of falling, in principle in the vicinity of
one of the two end anchors.
The user must use a mobile anchor point (hereinafter referred to glider) and the associated
connector.
9.1.2. Use of the glider LDV001
The glider is attached to the cable side to the user see Fig. 38
Fig. 23 Correct orientation of the glider
To connect the glider, the user tilts the glider, opens the locking device and fits the glider over the
cable - see Fig.7-8-9.
Fig. 24 Locking device open Fig. 25 Locking device closed Fig. 26 Karabiner on the glider
