fallprotec Securope 2012 - Turnbuckle; Cable Guide for Curve

User Manual
Securope 2012 horizontal
DOC039-UK-19.07.15
8
1.3.10. Turnbuckle
The turnbuckle allows end to end attachment of the wire rope in case of a closed loop.
Fig. 10 LDV138 Turnbuckle
1.3.11. Cable guide for curve
The cable guide for curve is used in conjunction with the corner plate and allows the tensioning of
the cable from one of the ends of the line.
Fig. 11 LDV076 Cable guide for curve
