FALMEC PLANE User Manual

3
ø160 mm
75 mm
70 mm
265 mm
110 mm
316 mm
285,4 mm
200 mm
254,2 mm
ø6
ø120 mm
600
m
3
/h
Uscita laterale utilizzabile solo con controsotto.
Side outlet which can only be used with false ceiling.
Seitlicher Abzug nur mit Zwischendecke verwen-
dbar.
Sortie latérale utilisable uniquement avec faux-plafond.
Salida lateral utilizable solo con falso techo.
 ,    
 .
Wylot boczny, wykorzystywany tylko na sutach
podwieszanych.
Saída lateral utilizável apenas com revestimento do teto.
Udgang på siden kun til anvendelse med nedhængt loft.
Sidoutgång endast användbar med undertak.
Sivussa oleva poistoaukko käytettävissä vain
sisäkaton kanssa.
Sideutgang som kun kan brukes med undertak.
FORATURA1

FALMEC PLANE Specifications

General

Noise level	62 dB
Intensive speed	No
Number of speeds	4
Type of extraction	Ducted
Noise level (low speed)	49 dB
Maximum extraction power	800 m³/h
Lighting efficiency class	A
Noise level (medium speed)	56 dB
Minimum distance from gas hob	630 mm
Noise level (intensive speed)	68 dB
Fluid dynamic efficiency class	C
Grease filtering efficiency class	B
Minimum distance from electric hob	520 mm
Type	Wall-mounted
Control type	Buttons
Product color	Stainless steel
Motor included	Yes
Exhaust location	Top
Bulb type	LED
Bulb power	1.2 W
Number of bulbs	2 bulb(s)
Grease filter type	Charcoal
Motor power	215 W
Connected load	280 W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	64 kWh
Package depth	450 mm
Package width	995 mm
Package height	595 mm
Package weight	23000 g

Weight and Dimensions

Depth	490 mm
Width	900 mm
Height	- mm
Weight	18000 g
Height (max)	1080 mm
Height without chimney	60 mm
