FALMEC PLANE User Manual

6
Ø8
Ø8
Ø8
V2 (x8)
V1
T
T1
ø8
V1 (x4)
4
3
2
1
T1
Ø8
Ø8
Ø8
V1
ø8
V1 (x4)
3
2
T1
SP
1
V4 (x8)
4
2
M
ERM
ERM
3
5
6
1
ø 15
ø 12
600
m
3
/h
150mm122mm
800
m
3
/h
C C1
D E
INSTALLAZIONE SU SOFFITTO CON/SENZA CONTROSOFFITTO  INSTALLATION ON CEILING
WITH/WITHOUT FALSE CEILING  DECKENINSTALLATION MIT/OHNE ZWISCHENDECKE  INS
TALLATION AU PLAFOND AVEC/SANS FAUXPLAFOND  INSTALACIÓN EN TECHO CON/SIN
CIELO RASO     /    MONTAŻ NASU
FITOWY, NA SUFICIE PODWIESZANYM LUB MUROWANYM  INSTALAÇÃO NO TETO COM/SEM
REVESTIMENTO NO TETO  INSTALLATION I LOFT MED/UDEN NEDHÆNGT LOFT  MONTE
RING I TAK MED/UTAN UNDERTAK  ASENNUS KATTOON SISÄKATOLLA TAI ILMAN  INSTAL
LASJON PÅ TAK MED/UTEN UNDERTAK.
INSTALLAZIONE SU SOFFITTO SENZA PROLUNGA H E TRALICCIO T  INSTALLATION ON CEILING
WITHOUT EXTENSION H AND TRELLIS T  DECKENINSTALLATION OHNE VERLÄNGERUNG H UND
GITTER T  INSTALLATION AU PLAFOND SANS RALLONGE H NI TREILLIS T  INSTALACIÓN EN TECHO
SIN EXTENSIÓN H Y ENREJADO T         
   MONTAŻ NA SUFICIE BEZ PRZEDŁUŻKI H I WYSIĘGNIKA T  INSTALAÇÃO NO TETO SEM
EXTENSÃO H E TRELIÇA T  INSTALLATION I LOFT UDEN FORLÆNGER H OG TREMMER  MONTERING
I TAK UTAN FÖRLÄNGNING H OCH FACKVERK T  ASENNUS KATTOON ILMAN JATKOKAPPALETTA H
JA KEHIKKOA T  INSTALLASJON PÅ TAK UTEN SKJØTEELEMENT H OG GITTERVERK T.

FALMEC PLANE Specifications

General

Noise level	62 dB
Intensive speed	No
Number of speeds	4
Type of extraction	Ducted
Noise level (low speed)	49 dB
Maximum extraction power	800 m³/h
Lighting efficiency class	A
Noise level (medium speed)	56 dB
Minimum distance from gas hob	630 mm
Noise level (intensive speed)	68 dB
Fluid dynamic efficiency class	C
Grease filtering efficiency class	B
Minimum distance from electric hob	520 mm
Type	Wall-mounted
Control type	Buttons
Product color	Stainless steel
Motor included	Yes
Exhaust location	Top
Bulb type	LED
Bulb power	1.2 W
Number of bulbs	2 bulb(s)
Grease filter type	Charcoal
Motor power	215 W
Connected load	280 W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	64 kWh
Package depth	450 mm
Package width	995 mm
Package height	595 mm
Package weight	23000 g

Weight and Dimensions

Depth	490 mm
Width	900 mm
Height	- mm
Weight	18000 g
Height (max)	1080 mm
Height without chimney	60 mm
