Delay:
Switches the Input delay on and off. This action is executed immediately and is immediate audible.
Meter: [m], Samples:, Feet: [ft] and Time: [ms]
All units can be incremented and decremented by 1 over the whole range.
Input EQ Menü
The Input EQ offers 7 identical filter stages named: E1 – E7. The whole filter unit can be bypassed
to compare a flat frequency response vs the filtered signall.
EQ:
With ‘EQ: off’ all 7 filter stages are bypassed and the signal response is flat. This action takes imme-
diately place, so that the differences are immediately audible.
E(n):
Each of the 7 EQ filter stages are default off. The settings will be displayed and accessible for ad-
justments if one of 6 available filter types has been selected.
The Rotary Function Dial navigates between the settings.
The current position is indicated by a triangle ( ).
Pressing the Push Button enables the adjustment of the settings by using the Rotary Function Dial.
A short press of the Push Button takes over settings, while a long press cancels the adjustment and
returns without modifications.
Modifications of Fc, Gain and Q are immediately audible. The new selected filter type will be audib-
le after confirmation (short press of the Push Button).
Filter-Type
Each EQ filter stage can be switched off or selected as:
Bell, Low Shelve 6 -, Low Shelve 12dB, High Shelve 6 -, High Shelve 12dB or Notch.
Gain for Bell, High and Low Shelve
The values ranges from -15dB to +15dB.
Settings resolution: 0 to +/-10dB in 0.5dB steps and above in 1.0dB steps.
Center / Corner Frequency (Fc)
The values ranges from 20Hz to 20kHz and can be adjusted with a precision of 1 Hz over the full
frequency range.
The frequency modification starts always first with the leftmost digit and follows the leftmost
position automatically.
This allows a very fast adjustment over the full frequency range.
Each press of the Push Button moves the decimal place toward the first digit.
A cursor indicates the position of the decimal place.
EQ (1:1+2)
EQ: off
E1: Bell 0.0dB
60Hz 1.0Q
E7: Bell 0.0dB
14000Hz 1.0Q
EXIT
EQ:
off
on
Gain:
-15dB
to
+15dB
FC:
20 Hz
to
20 kHz
Q:
0.5
to
20
Filter Type:
off
Bell
High Shelve 6/12dB
Low Shelve 6/12dB
Notch
