37
DEUTSCH ENGLISH
Channel EQ Menu
Filter-Type
Each EQ filter stage can be switched off or selected as:
Bell, Low Shelve 6 -, Low Shelve 12dB, High Shelve 6 -, High Shelve 12dB or Notch.
Gain for Bell, High and Low Shelf
The values ranges from -15dB to +15dB.
Settings resolution: 0 to +/-10dB in 0.5dB steps, +/-10 to 15dB in 1.0dB steps.
Gain for Notch
The individual damping for Notch is selectable from -3 to -18dB in 3dB steps and above from -20 to
-60dB in 20dB steps. Maximum is infinite damping indicated by a ‘-oodB’ in the display.
Center / Corner Frequency (Fc)
The values ranges from 20Hz to 20kHz and can be adjusted with a precision of
1 Hz over the full frequency range.
The frequency modification starts always first with the leftmost digit and follows the leftmost
position automatically.
This allows a very fast adjustment over the full frequency range.
Each press of the Push Button moves the decimal place toward the first digit.
A cursor indicates the position of the decimal place.
Quality Q for Bell
The values ranges from 0.5 to 20.
Settings resolution: 0.5 to 1.0 in 0.1, 1.0 to 10 in 0.5, 10 to 20 in 5.0 steps.
Quality Q for Notch
The values ranges from 1 to 30.
Settings resolution: 1 to 10 in 1.0 steps, 10 to 30 in 5.0 steps.
XOVER Menus
XOVER LPF (Low Pass Filter)
XOVERLPF (A:A+B)
Type: ButterW
Order: 18dB
FC: 20Hz
EXIT
XOVERHPF (A:A+B)
Type: ButterW
Order: 18dB
FC: 20Hz
EXIT
Orde:
6dB
to
24dB
Orde:
6dB
to
24dB
FC:
20 Hz
to
20 kHz
FC:
20 Hz
to
20 kHz
Filter Type:
off
Butterworth
Linkwitz
Filter Type:
off
Butterworth
Linkwitz
XOVER HPF (High Pass Filter)
