13
1: Power Connection for IEC cable
2: Speaker Twist Output
3: Screw Terminal Output
4: Line Output XLR
5: Line Input XLR/Jack Combo socket
6: Mode Switch (Bridge, Stereo, Parallel)
7: Sensitivity Switch
8: HPF Switch (120Hz, 90Hz, Bypass)
MS 5002
MS 8002 / MS 12002
Rear panel
Exclusively use fully functioning cables in perfect working condition! Please ensure that
the rated performance of your speakers is sufficient.
Model MS 5002 MS 8002 MS 12002
Capacity 8 Ohm
Stereo Operation
2x 350 Watts 2x 550 Watts 2x 720 Watts
Capacity 4 Ohm
Stereo Operation
2x 520 Watts 2x 820 Watts 2x 1120 Watts
Capacity 8 Ohm
Bridge Operation
1040 Watts 1640 Watts 2240 Watts
Frequency
(Bypass)
20Hz - 20KHz -1dB 20Hz - 20KHz -1dB 20Hz - 20KHz -1dB
Input Sensitivity 775mV 775mV 775mV
Signal to Noise 96dB 96dB 96dB
THD 50% Pmax
(1KHz)
0,07% 0,07% 0,07%
Damping Factor
(1KHz)
>200 >200 >200
Crosstalk >65dB >65dB >65dB
Class AB H H
Cooling System 2 Phase Fan 2 Phase Fan 2 Phase Fan
Power Supply AC: 220-230V 50Hz AC: 220-230V 50Hz AC: 220-230V 50Hz
Safety Soft Start, Short Circuit, Limiter, DC Fault, AC Line Fuse, Thermal Cut
Weight 13,8Kg 16,6Kg 19,1Kg
Technical Data
!
!
