FAME MS 5004 - Rear Panel and Technical Data; Rear Panel Connections; Technical Specifications

9
DEUTSCH ENGLISH FRANCAIS
1: Power Connection for IEC cable
2: Speakon Output
5: Line Input XLR
6: Mode Switch (Bridge, Stereo)
Rear panel
Exclusively use fully functioning cables in perfect working condition! Please ensure that
the rated performance of your speakers is suffi cient.
Model MS 5004 MS 8004
Capacity 8 Ohm
Stereo Operation
4x 350 Watts 4x 550 Watts
Capacity 4 Ohm
Stereo Operation
4x 520 Watts 4x 820 Watts
Capacity 8 Ohm
Bridge Operation
1040 Watts 1640 Watts
Frequency
(Bypass)
20Hz - 20KHz ± 0,5dB 20Hz - 20KHz ± 0,5dB
Input Sensitivity 1 Vrms @ 4 Ohm 1 Vrms @ 4 Ohm
Signal to Noise ≥ 102dB ≥ 102dB
THD 50% Pmax
(1KHz)
0,02% 0,02%
Damping Factor
(1KHz)
>200 >200
Class H H
Cooling System 2 Phase Fan 2 Phase Fan
Power Supply AC: 230V 50-60Hz AC: 230V 50-60Hz
Weight 18,3Kg 19,6Kg
Technical Data
