24
Specifications:
Portable DVD Player:
Compatible Disc: DVD /VCD/CD/MP3/JPG/MPEG-4
Signal System: PAL/NTSC
Screen Size: 9 Inch
Frequency Response: 20Hz to 20KHz
Video Output: 1 Vp/p/75 Ohm, Unbalanced
Audio Output: 1.4Vrms/10 KOhm(1 KHz,0dB)
Audio S/N: Better than 60 dB
Dynamic range: Better than 85 dB
Laser: Semiconductor Laser, Wave Length:650nm/795 nm
Power source: DC9-12V
Power Consumption: 12W
Working temperature: 5-40
Weight: 0.9KGS
Dimensions(LxWxH): 250x43x180mm
Note:This Manual is only for your reference. Changes to the design
and specification may be made without notice.
