Fantech 2SHE0721 Series - Replacement Parts List

3
O
perating Instructions and Parts Manual
Figure 3 — Replacement Parts Illustration
2SHE07 thru 2SHE36
1 Propeller 1 1 1
2
Shutter
1
1
1
3 Guard 1 1 1
4 Motor 1 1 1
5 Yoke brace — 1 1
6 Grommet — 4 —
7 10 x 3/4” Flat washer* — 4 4
8
3/8-24 x 1” HHCS screw*
—
1
1
9
3/8-24 Spinlock nut* — 1 1
10 #10-32 Spinlock nut* — 4 4
11
#10-16 x 5/8” S.M. screw*
4
4
—
12 3/8 x 13/16” Flat washer*
—
1
—
13 #8-32 Spinlock nut* 4 — —
14 #10-32 x 1.0 HWH screw — — 8
(*) Standard hardware items, available locally.
2SHE0721 thru 2SHE1221,
Ref. 2SHE1661, 2SHE1871 2SHE18B1, 2SHE20 thru 2SHE24 2SHE30C1, 2SHE36D1
No. Description Qty. Qty. Qty.
Replacement Parts List
2
6
1
10, 13
3
12
11, 14
7
5
8
4
9
