Faraday 15220A - Page 31

III- 16
U.L. COMPATIBLE 2-WIRE SMOKE DETECTORS
(Cont'd)
FOR 15220A AND 15240A FIRE ALARM SYSTEM CONTROL UNITS
(ZONE IDENTIFIER “C”)
DETECTOR MANUFACTURER NUMBER OF MAXIMUM
W/BASE DETECTOR DETECTORS STANDBY DETECTOR BASE
ORDER NO. W/ BASE PER CIRCUIT CURRENT INENTIFIER IDENTIFIER
SYSTEM SENSOR, DIV. of PITWAY CORP.
9183 W/9185 2151 W/B110LP 0-25 0.120ma. A A
9183 W/9448 2151 W/B116LP 0-25 0.120ma. A A
9184 W/9185 1151 W/B110LP 0-30 0.120ma. A A
9184 W/9448 1151 W/B116LP 0-30 0.120ma. A A
9418 1100 0-30 0.100ma. A —-
9419 2100 0-30 0.100ma. A —-
9420 2100T 0-30 0.100ma. A —-
9447 W/9361 5451 W/B401B 0-25 0.120ma. A A
9447 W/9364 5451 W/B401 0-25 0.120ma. A A
9447 W/9424 5451 W/B406B 0-25 0.120ma. A A
9421 W/9361 4451HT W/B401B 0-25 0.120ma. A A
9421 W/9424 4451HT W/B406B 0-25 0.120ma. A A
9421 W/9364 4451HT W/B401 0-25 0.120ma. A A
Notes: 1.) For specific wiring and installation information read the instructions provided with each device.
2.) For initiating circuit specifications, see the 15220A wiring diagram or 15240A wiring diagram.
3.) These detector models may be mixed and matched as long as total maximum standby current does
not exceed 3.0 ma. per zone. The total number of detectors on an initiating circuit should not exceed 30.
4.) The control unit is not intended to handle more than one 2-wire detector in alarm, per zone.
5.) The activation of a manual pull station or any other contact device will prevent any 2-wire detector on the
same zone from remaining activated or from activating.
*6.)The Hochiki Smoke Detector models may be mixed on the same initiating circuit, but they must not be mixed
with any of the other manufacturer's detectors. The total number of detectors on an initiating circuit must not
exceed 30.
