III- 29
COMPATIBLE SIGNALS (cont'd)
Audible Audible Strobe Strobe
Cat. No. Description Voltage Current Voltage Current
6302-D Mini-Horn w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.175A.
6302-S Mini-Horn w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.245A.
6302-(A,B) (*2) Mini-Horn w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.145 A
6302-C (*2) Mini-Horn w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.285 A
6304-E Mini-Horn w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.059A.
6304-G Mini-Horn w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.089A.
6304-J Mini-Horn w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.155A.
6304-K Mini-Horn w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.164A.
6304-L Mini-Horn w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.249A.
6304-M (*2) Mini-Horn w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.059A
6304-R (*2) Mini-Horn w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.088A
6304-T (*2) Mini-Horn w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.154A
6304-Y (*2) Mini-Horn w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.170A
6304-Z (*2) Mini-Horn w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.249A
6310 Mini-Horn-S/T 20-31VDC 0.025A.
6311 Mini-Horn-S/T 20-31VDC 0.025A.
6312-(N,W) Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.079A.
6312-D Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.175A.
6312-S Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.245A.
6312-(A,B) (*2) Mini-Horn-S/T w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.145 A
6312-C (*2) Mini-Horn-S/T w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.285 A
6314-E Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.059A.
6314-G Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.089A.
6314-J Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.155A.
6314-K Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.164A.
6314-L Mini-Horn-S/T w/ Strobe 20-31VDC 0.025A. 21-32VDC 0.249A.
6314-M (*2) Mini-Horn-S/T w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.059A
6314-R (*2) Mini-Horn-S/T w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.088A
6314-T (*2) Mini-Horn-S/T w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.154A
6314-Y (*2) Mini-Horn-S/T w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.170A
6314-Z (*2) Mini-Horn-S/T w/ Sync Strobe 20-31VDC 0.025A. 20-31VDC 0.249A
6320 (*2) Sync Electronic Horn 20-31VDC 0.030A.
6321 (*2) Sync Electronic Horn 20-31VDC 0.030A.
6322-(A,B) (*3) Sync Electronic Horn w/ Sync Strobe 20-31VDC 0.030A. 20-31VDC 0.145 A
6322-C (*3) Sync Electronic Horn w/ Sync Strobe 20-31VDC 0.030A. 20-31VDC 0.285 A
6380 Electronic Signal-8T 20-31VDC 0.024-0.050A.(*4)
6381 Electronic Signal-8T 20-31VDC 0.024-0.050A.(*4)
6382-(N,W) Electronic Signal-8T w/ Strobe 20-31VDC 0.024-0.050A.(*4) 21-32VDC 0.079A.
6382-D Electronic Signal-8T w/ Strobe 20-31VDC 0.024-0.050A..(*4) 21-32VDC 0.175A.
6382-S Electronic Signal-8T w/ Strobe 20-31VDC 0.024-0.050A.(*4) 21-32VDC 0.245A.
6382-(A,B) (*2) Electronic Signal-8T w/ Sync Strobe 20-31VDC 0.024-0.050A.(*4) 20-31VDC 0.145 A
6382-C (*2) Electronic Signal-8T w/ Sync Strobe 20-31VDC 0.024-0.050A.(*4) 20-31VDC 0.285 A
Key:
(*1) Indicates Gong Size or Chime - 1 = 10" Gong, 4 = 4" Gong, 5 = Chime, 6 = 6" Gong, 8 = 8" Gong
(*2) Sync Strobe Light or Sync Electronic Horn require a 5405 or 5406 Sync Control Module.
The sync strobes and sync electronic horn must be connected to a compatible signal circuit with a steady
current output and appropriate voltage, with a 5405 or 5406 SYNC Control Module wired electrically before
the strobes.
(*3) Sync Electronic Horn and Sync Strobe Light require 5405 or 5406 Sync Control Module
(*4) See Installation Instructions for the current of the desired tone
CAT. NO. XXXX-0 = Strobe Light (UL1638 4.5 cd) Cat. No. XXXX-E = Strobe Light (UL1971 15/75cd)
CAT. NO. XXXX-H = Strobe Light (UL1638 15 cd) Cat. No. XXXX-G = Strobe Light (UL1971 30/75cd)
CAT. NO. XXXX-X = Strobe Light (UL1638 30cd) Cat. No. XXXX-J = Strobe Light (UL1971 60/75cd)
CAT. NO. XXXX-U = Strobe Light (UL1638 120 cd) Cat. No. XXXX-K = Strobe Light (UL1971 75cd)
CAT. NO. XXXX-W = Strobe Light (UL1971 15/75 cd) Cat. No. XXXX-L = Strobe Light (UL1971 110cd)
CAT. NO. XXXX-N = Strobe Light (UL1971 15 cd) Cat. No. XXXX-M = Sync Strobe Light (UL1971 15/75cd)
CAT. NO. XXXX-D = Strobe Light (UL1971 75 cd) Cat. No. XXXX-R = Sync Strobe Light (UL1971 30/75cd)
CAT. NO. XXXX-S = Strobe Light (UL1971 110 cd) Cat. No. XXXX-T = Sync Strobe Light (UL1971 60/75cd)
CAT. NO. XXXX-A = Sync Strobe Light (UL1971 15 cd) Cat. No. XXXX-Y = Sync Strobe Light (UL1971 75cd)
CAT. NO. XXXX-B = Sync Strobe Light (UL1971 15/75 cd) Cat. No. XXXX-Z = Sync Strobe Light (UL1971 110cd)
CAT. NO. XXXX-C = Sync Strobe Light (UL1971 75 cd)
