3 DESCRIPTION OF THE PRODUCT
Picture 1 –Dental Light – Unit Mount
Picture 2 –Dental Light – Ceiling Mount
The device is available in two main product variants:
- EVA with light source at 5000 K with “Sunlight” Spectrum
- EVA with Tunable White light source (4000 K, 5000 K, 5700 K, Composave setting (2700 K)) selectable by the operator.
These main variants can be supplied with:
- Different Mounting:
- Different arm length combination
- Canbus Technology
- Remote cable for bring the command to the Dental Unit’s
- Auto-on setting;
- Theia Technology (secondary light source under fixed arm);
- Integrated Camera 2K or 4K;
- RF for the connection with FARO’s room lights (Siderèa)
All variants can be ordered by dedicated product codes as reported in the table below:
Mounting
1-2 DIGIT
Swivel Arm
3°DIGIT
Fixed Arm
4°DIGIT
Light Source /
Integrated Camera
5°DIGIT
Command /
radiofrequency (RF)
6°DIGIT
Cables
7° DIGIT
Custom
(1)
8°-9° DIGIT
5
U
0
Only Head
No arms
0
Only Head
No arms
0
Tunable White
0
Joystick
0
Stnadard
00
Std faro
5
C
1
550 mm
1
600 mm
1
Sunlight 5000K
1
Joystick RF
1
Remote Control
Bus Cable
JJ
(4)
5
T
2
855 mm
2
600 mm
Theia
2
Tunable White
Integrated Camera
2
Sensor
3
820 mm
3
Sunlight 5000K
Integrated Camera
3
Sensor RF
4
820 mm
Theia
4
cNus
Tunable
(2) (3)
5
960 mm
5
cNus
Sunlight 5000K
(2) (3)
6
960 mm
Theia
(1) Customized codes include only aesthetic customization having no impact on Safety and EMC requirements
(2) cNus mark for Noth Amercia cannot be coupled with the following variant codes:
Digit 1-2: 5T
Digit 3: 0
Digit 5: 2 – 3
(3) Ceiling Mounting Versions with cNus Mark are considered Fixed Applications and must be connected to Earth Protection. These devices are
Class 1 Insulation according to IEC 60601-1.
(4) Aesthetic branding customization not impacting on Safety and Performance requirements
