FIG. 33: Balatron 202 measures
APPENDIX
A: Technical Data
Absorbed power 5W
Speed Balancing 75-125 RPM
Measuring time 4-15 seconds
Precision ±1grs (±1/28 ounce)
Wheel balancer dimensions
B202
L (mm) 1030
L1 (mm) 500
L2 (mm) 1080
P (mm) 430
P1 (mm) 550
P2 (mm) 1250
H (mm) 940
H1 (mm) 1400
Peso (kg) 70
B: Environmental Data, Safety Features and Requirements
Environmental Data
[Operating conditions]
This unit is designed for indoor use only.
Temperature: 0 to 45°C Relative Humidity: 5 to 80% a 40°
[Storage conditions]
Package is designed for indoor storage only.
Temperature: -25° to 70°C Relative humidity: 5 at 95% to40°C
Safety Features
1. The Balance Weights Holder may be removed for servicing. It is secured to the machine body through screws so that only
voluntarily it may be removed. Removal of this protection is therefore restricted to Authorized Service Engineers.
2. The Control Panel may be removed for servicing. It is secured to the machine body through screws so that only voluntarily it
may be removed. Removal of this protection is therefore restricted to Authorized Service Engineers.
I WARNING FASEP 2000 srl shall not be responsible for any inconvenience, breakdown, accidents caused directly
or indirectly by unauthorized service. Service to any parts by unauthorized engineers will void warranty
and will any right of the owner of the unit.
G NOTE A safety cover is not required for hand launch wheel balancer.
