Fasep FZ41/3S - Page 25

2 column
electro-mechanical lift
Mod. Z41/3S
26
33 SUPPORT
34 MOTOR
35 BEARING
36 MICRO
37 ELECTRICAL PANEL
38 SPRING
39 BELT
40 WASHER
41 NUT
42 SCREW
43 SCREW
44 NUT
45 NUT
46 GRUB SCREW
47 GRUB SCREW
48 TAB
49 TAB
50 WASHER
51 SCREW
52 SCREW
53 SCREW
54 SCREW
55 SCREW
56 SCREW
57 WASHER
58 SCREW
59 CABLE
60 GREASE NOZZLE
61 SCREW
62 WASHER
63 NUT
64 STRAP
No. DESCRIPTION
1 PULLEY
2 PULLEY
3 FOOT PROTECTION
4 COVER
5 PLATE
6 CAP
7 PLATE
8 PLATE
9 BRACKET
10 CAM
11 PLATE
12 BRACKET
13 BRACKET
14 STOPPER
15 SCREW
16 SPACER
17 NUT
18 SPACER
19 SPACER
20 COLUMN
21 FOOT PROTECTION
22 LID
23 BRACKET
24 ROD
25 PINION
26 BUSHING
27 SHEAVE
28 SPRING
29 SUPPORT
30 WASHER
31 NUT
32 SCREW
