2 column
electro-mechanical lift
Mod. Z41/3S
33
ACRONY
M
DESCRIPTION FUNCTION
QS1 MAIN SWITCH MAIN LINE SWITCH
KM1 CONTACTOR MOTOR CONTACTOR
CS PHASE SEQUENCE RELAY PHASE CONTROL
QF1 CIRCUIT BREAKER MOTOR PROTECTION
FU1 FUSES TRANSFORMER PRIMARY PROTECTION
TC1 TRANSFORMER TRANSFORMER
FU2 FUSE TRANSFORMER SECONDARY PROTECTION
HL1 WARNING LIGHT MOTOR GEAR
PE MUSHROOM-SHAPED BUTTON EMERGENCY
S2 LIMIT SWITCH UP LIMIT SWITCH
S3 LIMIT SWITCH DOWN LIMIT SWITCH
S1 LIMIT SWITCH CONTROL LIMIT SWITCH
P1 BUTTON UP BUTTON
P2 BUTTON DOWN BUTTON
