D0 CLASSIFICATION OF THE CRANE MODEL
The design of this crane has been carried out in respect of DIN 15018 norms,
fatigue test classification H1B3.
The crane can operate, intermittently, with lifting devices other than the hook.
The dimensions and the capacity of the implements must be proportioned with
crane performances.
D0.1 Technical data
D0
CLASSIFICATION OF
THE CRANE MODEL
F 170A.23
9
ST 170
F170A.23
F 170A.23
Lifting Standard Hydraulic Rotation Rotation Working Pump Oil tank Crane Max. working
capacity reach extension arc torque pressure capacity capacity weight pressure
on the outrigger
(Φ 200)
15,39 tm 10,40 m 5,75 m 400° 2,86 tm 29,5 MPa 40 l/min 120 l 2305 kg 30 daN\cm
2
151,0 kNm 28,1 kNm
