Fastcorp, LLC
DIVI Setup and Users Guide
Page 40 of 62 Rev 6
Instructions to Flash Update DIVI Firmware After Revision V119K2
33. The DIVI firmware after revision V119K2 provides many upgrades that have enhanced the
functionality and versatility of the DIVI Vendor. More notable additions include the ability to:
a) Load a machine configuration from a Micro SD card
b) Save a machine configuration to a Micro SD card
c) Load new Firmware from a Micro SD card
d) Save DEX sales data to a Micro SD card
If the user selects “Load New Firmware”, the firmware will automatically save a copy of the existing programming
configuration before starting the firmware upgrade. Once the firmware upgrade is complete, the new firmware
will automatically look to see if a programming configuration had been saved and will restore that configuration
into its operational memory.
If it is necessary to save a bin configuration or DEX data to a Micro SD card, the naming convention used is similar
to that once used in cell phone technology for texting and saving phone numbers:
1
2
3
4
5
6
7
8
9
0
International Standard
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
WXYZ
Fig. 12 Phone Dial Pad
To name a configuration, “BINS”:
e) Press the number 2 twice = B
f) Press the number 4 three times = I
g) Press the number 6 twice = N
h) Press the number 7 four times = S
If you make a mistake, use the * key to scroll backwards and clear an entry.
 Although DEX sales data remains untouched throughout the program upgrade process, the user
should manually save a copy of DEX sales data to the Micro SD card before upgrading the firmware.
 Instructions to Update Firmware after Revision V119K:
 Necessary tools and components:
 Micro SD Card – 1GB to 8GB.
 Open the DIVI machine door.
 Open the inner door located to the left of the window opening on the inside of the door.
 The VMC Board is located at the top of the opening and the Digital Display Board is located directly
below the VMC. Unlatch the right side of the Display Board and flip it around so that the display may
be viewed from the back of the door.
 The Microprocessor (daughter) Board is located on the upper right corner of older VMC Boards. Newer
versions incorporated all functions into the VMC board. Remove the Micro SD card from its SD adapter and
carefully insert it into the metallic slot located on the upper right corner of the VMC board.
