www.fastech-motions.com - 15
Purpose Item Part Number Manufacturer
Power (CN1)
Housing
Terminal
5557-02R
5556T
MOLEX
Motor
Drive side
(CN2)
Housing
Terminal
5557-04R
5556T
MOLEX
Motor side
Housing
Terminal
5557-04R
5556T
Signal (CN3)
Housing
Terminal
PAP-10V-S
SPHD-002T-P0.5
JST
13.2 Connector Specifications
Connector specifications for cabling to drive.
※ Above connector is the most suitable product for the drive applied. Another equivalent connector can be used.
