Fastech Ezi-Step ST - Connector Specifications

www.fastech-motions.com - 20
Purpose Item Part Number Manufacturer
Power
(CN1)
Terminal Block AK950-2 PTR
Motor
Drive Side
(CN2)
Terminal Block AK950-4 PTR
Motor Side
Housing
Terminal
3191-4R1
1381T
MOLEX
Signal
(CN3)
Terminal Block AK950-10 PTR
16.2 Connector Specifications
Connector specifications for cabling to drive.
※ Above connector is the most suitable product for the drive applied. Another equivalent connector can be used.
