FATEK FBe-40MC - Page 50

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
50
4H)
• 1:1 Connection
• 1:n Connection
• The 5V output (Pin #6) on the Display is the power for the Siemens AG’s PROFIBUS
connector. Do not use it for other devices.
• In COM on the GP-4107, the SG and FG terminals are isolated.
External Device
Terminal block
Signal name
D+
D-
FG
Signal name
NC
1
LINE(-)
8
GND(SG)
5
4
RS(RTS)
NC
NC
2
7
NC
9
FG
LINE(+)3
5V
6
D-Sub 9 pin (plug)
Display
Pin
Shell
Display
Terminal resistance: ON
120
(1/2W)
Terminal
resistance
Ω
Shield
External Device
Terminal block
Signal name
D+
D-
FG
Signal name
NC
1
LINE(-)
8
GND(SG)
5
4
RS(RTS)
NC
NC
2
7
NC
9
FG
LINE(+)3
5V
6
D-Sub 9 pin (plug)
Display
Pin
Shell
Display
Terminal resistance: OFF
120
(1/2W)
Terminal
resistance
Ω
Shield
External Device
Terminal block
Signal name
D+
D-
FG
Terminal resistance: ON
Shield
