FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
55
5E)
5F)
Number Name Notes
(1)
RJ45 RS-232C Cable (5m) by Pro-face
PFXZLMCBRJR21
Number Name Notes
(1)
RJ45 RS-232C Cable (5m) by Pro-face
PFXZLMCBRJR21
D-Sub 9 pin (plug)
C
onnection
C
able
2
3
5
Signal name
TXD
RXD
SG
Pin
FB-232P0-9F-150
External Device
D-Sub 15 pin (socket)
Display
GND
TXD
RXD
(1)
D-Sub 9 pin (socket)
C
onnection
C
able
3
2
5
Signal name
TXD
RXD
SG
Pin
FB-232P0-9M-150
External Device
D-Sub 15 pin (socket)
Display
GND
TXD
RXD
(1)
